L2-060X-024A 60W 24V 5-in-1 Dimmable LED Driver

L2-060B-024A is a 60W 24V constant-voltage LED driver developed for professional architectural lighting, signage, advertising lighting and LED strip applications. It accepts a wide 100-277Vac input and provides a regulated 24Vdc / 2.5A output. With power factor above 0.95 and typical efficiency of 88%, the unit is designed for projects that need reliable LED power conversion together with dimming control.

60W 24V 5-in-1 dimmable LED driver for professional lighting projects

As a 5-in-1 dimmable constant-voltage LED power supply, L2-060B-024A is intended for installations where the lighting level needs to be adjusted while maintaining a stable DC output. The L2-A platform combines Class 2 power-supply construction, an IP65 metal enclosure and 0-100% flicker-free dimming capability stated for the series. It is suitable for dry, damp and wet-location lighting projects where a protected dimmable LED driver is preferred over an open-frame power supply.

Its single-output architecture is well suited to compact lighting zones, short-to-medium LED strip runs, illuminated signs and localized architectural lighting circuits. The 60W class provides a practical balance for retail displays, channel letters, feature lighting and medium-length LED strip installations where dimming capability and enclosure protection are required. The 24V DC output is particularly useful for longer LED strip runs and architectural linear lighting, where a 24V system can help reduce operating current compared with an equivalent 12V load.

Key specification considerations

For engineers, lighting manufacturers and project buyers comparing a 60W LED driver, the important selection points are the 24V constant-voltage output, 2.5A output capacity, 100-277Vac input range, IP65 enclosure, PF >0.95 and the L2-A multi-dimming platform. The enclosure size for this model is 137×121.5×46 mm. Built-in protection for the series includes SCP, OVP, OTP and OLP, helping support stable operation in demanding LED lighting installations.

In search and specification terms, L2-060B-024A fits requirements such as 60W 24V dimmable LED driver, 100-277V AC to 24V DC LED power supply, IP65 Class 2 LED driver, constant-voltage driver for LED strip lights and dimmable LED power supply for signage and architectural lighting. FAHOLD offers a 5-7 years warranty warranty for this L2-A product line.
