T1-040X-054 40W 27-56V Outdoor LED Driver

T1-040X-054 is a compact 40W outdoor LED driver from the FAHOLD T1 Series, developed for professional street lighting, tunnel lighting, display lighting and other outdoor LED applications. It operates from 100-277Vac input and provides a 27-56V output-voltage range with a full-power output-current range of 0.74-1.11A. The compact T1 platform extends the F1 family into lower-power applications where installation space and current flexibility are important.

40W 27-56V Outdoor LED Driver for Compact Lighting Fixtures

For luminaire manufacturers and lighting engineers, T1-040X-054 is relevant to specifications such as 40W outdoor LED driver, 100-277V LED power supply, 0-10V dimmable LED driver, compact street light driver, tunnel lighting power supply and IP67 outdoor LED driver. The 40W version is suited to compact street, tunnel and display-lighting fixtures that need a small programmable driver with outdoor-grade protection.

Dimming and Control Options

In the official T1 model code, X remains the control-option placeholder used for the available B, V and D configurations. Type B is dimmable and supports off-line programming, Type V is non-dimmable with potentiometer adjustment, and Type D is DALI dimmable. The product family also supports 0-10V, PWM, resistor and timer-dimming functions according to the selected configuration.

Electrical Performance and Protection

The principal parameters for T1-040X-054 include 40W rated power, 27-56V output voltage, 0.74-1.11A current range, power factor of >0.95 and typical efficiency of 88.00%. The enclosure measures 108.5×62×32 mm. The series uses IP65 / IP67 outdoor protection and includes SCP, OVP and OTP protection. Surge protection is specified at DM 6kV / CM 10kV.

Relevant long-tail search terms include 40W 0-10V LED driver, 40W compact outdoor LED driver, 27-56V LED power supply, programmable street lighting driver, IP65 IP67 tunnel light driver and 100-277V constant-current LED driver. FAHOLD specifies a 5+ years warranty.
